How to Fit a Canvas Board into a St Ives Float Frame

How to fit a canvas board into a St Ives float frame with double-sided VHB tape, keeping the gap even on all four sides. Seven steps and a video.

By EasyFrame, Bedford. Updated October 2026. 2 minute read.

Fitting a canvas board into a St Ives float frame is quick. Your board rests on the frame's inner section, with an even gap all round between its edges and the outer wall, so it appears to float. This short guide shows how to fix it in place and get the gap even.

How to fit a St Ives float frame

Video: how to fit a canvas board into a St Ives float frame.

Prefer our earlier video? Watch “How to Fit a Canvas Board in a Float Style St Ives Frame” on YouTube.

You'll need

  • your St Ives float frame (standard or wide profile);
  • your canvas board;
  • good double-sided VHB tape: a strong foam tape, such as our 9mm roll, which you can add on the frame's page;
  • a tape measure;
  • clean hands, or gloves, and a clean, flat surface to work on.
An empty St Ives float frame on a table, seen from above, with the tools needed.
The frame, ready to fit.

How a float frame works

The board sits on top of the frame's inner section, held with double-sided tape, and overhangs it by about 5mm, so its edges are on show. Between the edges of the board and the frame's outer wall there's a gap of about 15mm (standard profile) or 25mm (wide profile) on every side.

Cross-section of a St Ives float frame: the board rests on the inner section with a 5mm overhang, held with double-sided tape.
The board on the inner section, seen from the side.

Step by step

1. Check the size

Before you start, lay the board in the frame to check it's the right size: there should be a gap of about 15mm (standard profile) or 25mm (wide profile) on every side.

The board laid in the frame, with a gap of 15mm marked on each side.
About 15mm on every side.

2. Apply the tape

Lift the board out again. Run a continuous line of double-sided VHB tape along all four sides of the inner section.

3. Peel back a little of the liner

Peel back the tape's liner carefully, exposing only a small section of adhesive to begin with, so you can still adjust the board once it's in.

Tape with its red liner along all four sides of the inner section.
Tape on all four sides.
The liner peeled back a little at each end of each strip.
A little of the liner peeled back.

4. Position the board

Lower the board gently into the frame, and take your time placing it.

5. Check the gaps

Look to see that the gaps are even all round, then check with a tape measure that they're the same on all four sides. Make any small adjustments now, while only a little of the tape is exposed.

The board in the frame, the gap measured at 15mm on all four sides.
Even gaps: 15mm all round.

6. Secure the board

Once it's in position, press gently near the exposed tape. Then pull out the rest of the liner from under the board, and press firmly and evenly all round the board so the tape bonds well.

The board fixed in the frame, with an even gap all round.
Fixed in place.

7. Add the hanging fixtures, and hang it

Fit your hanging fixtures, such as D-rings and cord or a sawtooth hanger, to the back of the frame. Then hang your framed piece where you can enjoy it: the float frame gives it a modern, gallery-style finish.

The back of the frame with a D-ring on each side and a cord between them.
D-rings and cord on the back.
The framed board hanging on a wall.
Hung, and floating.

Tip: work on a clean, flat surface, and handle the frame and board with clean hands, to avoid marks.
